Supports 13th / 12th Gen Intel Core, Pentium Gold, and Celeron Processors*

* Refer to www.asus.com for the CPU support list.

Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0*

* Intel Turbo Boost Max Technology 3.0 support depends on the CPU type.

Supported only by CPU with integrated graphic

DDR4 5333(OC) / 5000(OC) / 4800(OC) / 4600(OC) / 4400(OC) / 4266(OC) / 4000(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3333(OC) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 *

* Actual memory data rate depends on the CPU types and DRAM modules, for more information refers to www.asus.com for the Memory QVL (Qualified Vendors Lists).

1 x PCI Express 4.0 x16

* Actual support may vary by CPU.

Intel 12th Gen Processors:
M.2_1 slot (Key M), type 2242/2260/2280
– Intel 12th Gen processors support PCIe 4.0 x4 mode.Intel B660 Chipset*:
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4)* Intel Rapid Storage Technology supports Intel Optane Memory H Series on PCH attached M.2 slots.

7.1 Channels*

* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.

4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x D-Sub port
1 x HDMI port
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port

1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports

Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Miscellaneous
1 x RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x S/PDIF Out header
1 x Speaker header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin System Panel header

1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector

Accessories
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x I/O Shield
2 x M.2 anchors
Installation Media
1 x Support DVD
Documentation
1 x User manual
